Plastic silicate silate smelt and iron oxide - gold.

Published:2024-02-19 Views: Source:

1.1 Plastic silicate mixed with a variety of oxidationIron

Figure1.16-1For the visible field, the deep gray in the cracks is plastic silicate mixed with the murky, and the second layer is lighter with iron oxide.

Figure1.16-2For the dark field of view, silicate is transparent, iron oxides are dark, and cracks and gaps are transparent.





Figure1.15-1 The Cracks Show                            Figure 1.15-2The Cracked Dark Field





The following are the products that will be used for gold phase:

1. FY-QG-65, a Fuyunkin co-moder, cut the sample gold and cut down a small piece, horizontal or vertical, as required by the sample, to facilitate mosaicing.





II. Kim Co-simworks:

Fuyun materials gold-specific sandpaper: 230mm diameter without glue 600# 1200# 2500#



III. LEAVE THE FIELDS OF THE KING PHOTOS:

Fuyun materials gold-phased photo fabric: 230 mm in diameter velvet/splendon

Fuyun materials, Fresco-Frestilt Spraying: 1/3 micrometre

Fuyun machine: manual in no-extreme-speed grinder

Pressure: Fixed, neutral, stable, without too much pressure.

Time: 2-5 minutes, whichever is the same, the scratches of the thin sandpaper are almost removed.

Rotation speed: 200 turns

Raarboard direction: Clockwise

During polishing: The polished rags need to be immersed early, the polished fluid is down in the centre position and handwashing is added to its lubrication.

Pour: A little bright, no scratches, and can move on.


During polishing: The polished rags need to be immersed early, the polished fluid is down in the centre position and handwashing is added to its lubrication.

Pouring: The brightness is very high.

Corrosion observation:

Fuyun gold microscope (magnification multiple: 50X, 100X, 200X, 500X, 1,000X)



The following are used for corrosive reagents:
